TTL CONTROLLED WAVEGUIDE SWITCHES (MOTORIZED)
7.05 to 50.0 GHz LATCHING TYPE
|
|
|
7.05 to 50.0 GHz LATCHING TYPE |
TTL CONTROLLED WAVEGUIDE SWITCHES (MOTORIZED)
This series of switches has many
of the attributes of the latching type design with the addition of TTL
control. These switches are made of aluminum.*
This standard R.F. section is available as a DPDT (4 port) type with
paths of the continuous arc design or optional SPDT (3 port).
The drive section utilized a modified Geneva linkage and brushless type
motor for smooth, dependable operation.
For custom features, contact Waveline sales or engineering. These
switches can be pressurized upon request. Alternate flanges and materials
are available. See flange section. Finish in instrument gray enamel.
| General Specifications: | Important Ordering Information: |
| VSWR.................................1.10
Maximum *Isolation........................70 dB Minimum Voltage ...........................28 VDC Life..........................250,000 operations minimum Temperature Range. -54 degrees C to +85 degrees C Switching Time............................50 mS. maximum Switching Current.......................1.4 Amps maximum |
Example
689-E-P-SP |
| WG Size |
Frequency Range, GHz |
Equivalent Flange Type |
Insertion loss dB |
Avg. Power |
Inches A Max. |
Inches B |
Inches C |
Inches D |
Inches E |
Inches F Holes |
Model No. |
| WR-112 | 7.05 to 10.0 | UG-138/U Cover | 0.05 | 6 kW | 4.97 | 1.109 | 2.250 | 2.25 | 1.875 | #6-32 | 589-E |
| WR-102 | 7.00 to 11.0 | WR-102 Cover | 0.06 | 5 kW | 5.13 | 1.156 | 2.375 | 2.38 | 1.750 | #8-32 | 0289-E |
| WR-90 | 8.20 to 12.4 | UG-135/U Cover | 0.07 | 4 kW | 4.77 | 1.016 | 2.000 | 2.25 | 1.625 | #6-32 | 689-E |
| WR-75 | 10.0 to 15.0 | WR-75 Cover | 0.07 | 3 kW | 4.73 | .900 | 1.800 | 2.25 | 1.375 | #6-32 | 7589-E |
| WR-62 | 12.4 to 18.0 | UG-1665/U Cover | 0.10 | 2 kW | 4.50 | .812 | 1.625 | 2.25 | 1.280 | #6-32 | 789-E |
| WR-51 | 15.0 to 22.0 | WR-51 Cover | 0.15 | 1.5 kW | 4.28 | .750 | 1.625 | 2.25 | 1.280 | #6-32 | 5189-E |
| WR-42 | 18.0 to 26.5 | UG-597/U Cover | 0.20 | 750 W | 4.13 | .656 | 1.500 | 2.25 | 1.125 | #6-32 | 889-E |
| WR-28 | 26.5 to 40.0 | UG-599/U-AL Cover | 0.20 | 400 W | 3.85 | .532 | 1.500 | 2.25 | 1.125 | #6-32 | 1089-E |
| WR-22 | 33.0 TO 50.0 | WR-22 Rd. Cover | 0.30 | 350 W | 4.36 | .687 | 1.375 | 2.25 | 1.062 | #6-32 | *1189-E |
|
*Model No. 1189-E 50 dB minimum. Material OFHC Copper |
| Please call if you need any further assistance or information. |
|
51 |
|
P.O. BOX 718, West Caldwell, NJ (973) 808-9113 Fax (973) 808-1524 |
